Name: High Speed Milling GT-1290
Category: High Speed Milling
Product details
On the basis of inheriting the advantages of rigid rigidity, structural symmetry and strong stability of the traditional gantry machine frame, this machine introduces the international advanced dynamic rigid design concept and optimizes the design of moving parts. The machine tool has strong rigidity and fast response characteristics, which is suitable for various types of mold finishing. |
| PROJECT | DESCRIPITION | UNIT | GT-1290 |
| TRAVEL | Type of XYZ Axis Guide | High Rigid Roller Rail | |
| X-axis/Y-axis/Z-axis | mm | 1200/900/600 | |
Spindle nose end to working table | mm | 150-750(approximate value) | |
| Distance between two columns | mm | 1050(approximate value) | |
| Spindle nose end to working table | mm | 220-680(approximate value) | |
| TABLE | Workbench (long x wide) | mm | 1200x900 |
| Workbench load-bearing | kg | 1500 | |
| SPINDLE | Spindle speed/RPM | rpm | CVT20000rpm |
| Spindle bore taper/TYPE | HSK-A63 | ||
| FEED RATE | C00 Fast Feed (X/Y/Z) | mm/min | 20000/20000/10000 |
| G01 Cutting Feed | mm/min | 1-8000 | |
PRECISION | Location accuracy/repetition accuracy | mm | 0.008/0.005 |
OTHER | Machine weight | kg | 10000（About） |
